Processing Line / Tension Leveling
Tension Leveling Line
This page outlines elongation control, bridle zones, roll arrangement, feedback control, automation data, and downstream slitting or coating stability.
1780mm max listed width
800m/min listed speed
23-rollLeveler option
3Model families
Process design
Create a stable flatness window before cleaning, annealing, coating, or slitting.
JINYE specifies tension leveling equipment around material strength, strip thickness, defect pattern, elongation target, bridle arrangement, and line integration requirements.
- Flatness correction and residual stress relief after cold rolling.
- Single-leveler, double-leveler, and 23-roll leveler configurations.
- Project-specific tension zones, roll arrangement, strip protection, and feedback control.
- Integration with cleaning lines, annealing lines, and coil slitting lines.
Tension Leveling checkpoints.
| Model | Width classes | Speed range | Configuration focus |
|---|---|---|---|
| Double-bend single-leveler | 1780 / 1450 / 1150 / 1050 / 950 / 850 / 750 / 650 / 550 / 450 / 350mm | 500-800m/min | General flatness correction and inline finishing |
| Double-bend double-leveler | 1780 / 1450 / 1150 / 1050 / 950 / 850 / 750 / 650 / 550 / 450 / 350mm | 500-800m/min | Higher corrective capacity and tighter flatness targets |
| 23-roll tension leveler | 1780 / 1450 / 1150 / 1050 / 950 / 850 / 750 / 650 / 550 / 450 / 350mm | 500-800m/min | Thin strip finishing and refined flatness control |
Final model selection depends on material yield strength, thickness, flatness defect type, tension window, and adjacent line equipment.
